Quick and easy payment options to improve checkouts. Engage consumers with a large multimedia touchscreen. The following topics provide information for troubleshooting your Ingenico iSC Touch 250 device.Increase payment security with the first and only PCI PTS 5.x certified device Press X (red button) to return to the main menu. The current firmware version installed is displayed on the screen. Press O (green button) to select Version in the menu list. Press O (green button) to continue with a terminal reset. When finished, press O (green button) to save. Press O (green button) to save the value and continue using + to cycle between fields until all the values have been entered. Press < (yellow button) to erase the last value. Press O (green button) to enter a new value using the device number pad. Press + to cycle between the network setting fields. Press O (green button) to edit the static IP settings. Press < (yellow button) to toggle the setting from DHCP to Static. Press O (green button) to select Ethernet Properties. Press + to navigate down the list to Ethernet Properties. Press X (red button) on the device's number pad to return to the main menu. If your device requires a firmware update, contact CardPointe Support. Check your device's firmware version to confirm it is version 1.6.1 or higher. To manually set the network settings for the device, follow the steps below. Typically, the device is assigned an IP address automatically when connected to the network. Setting a static IP address for your device is optional. Setting a Static IP Address for Your Device
Press X (red button) to cancel or return to the main menu. Press +, 7, 6, 7 on the device's number pad to access the S.O.S. Menu allows you to access the device Version, Date and Time, Server Properties, and Ethernet Properties. The device may be left on indefinitely or may be disconnected from power as necessary. Once Connected, the device is ready for use. If the connection is unsuccessful, the device displays Disconnected, at which point you can contact us for troubleshooting. If the connection is successful, the CardPointe Integrated Terminal device displays Connected. Once the device has successfully established its IP Address, it will attempt to call the CardPointe Integrated Terminal service. Once power is supplied to the CardPointe Integrated Terminal device, an initiation process begins. Plug the power supply adapter into an available power outlet. Connect the other end of the Multipoint Interface Cable to an Ethernet port (router, modem, wall jack, etc.). Connect the Multipoint Interface Cable into the Multipoint Port on the back of the CardPointe Integrated Terminal device. Once your equipment is unboxed, plug the power supply connector into the jack on the Multipoint Interface Cable. Ingenico multi-point mono connector cable.
For detailed information on integrating with your CardPointe Integrated Terminal solution, see the CardPointe Integrated Terminal developer documentation. The following topics provide information for getting started with the iSC Touch 250. "Press the Red X to Cancel or the Green Circle to Bypass"
The Application Label, which describes the EMV application name read from the card (for example, "US Debit"). The Bolted and Unbolted statuses will change to Connected and Disconnected, respectively.Īdditionally, for Ingenico Lane terminals, the PIN entry prompt for EMV PIN Debit cards will now displays the following additional information:. If you are using the default device wallpaper and theme, the Bolt wallpaper and logo will change to CardPointe Integrated Terminal. Once your terminal is updated, you may notice the following changes: #Ingenico credit card machine update
Terminals will update automatically during the nightly reboot window therefore, we ask that you leave your terminals powered on and connected to your network overnight. Over the coming weeks, your terminals will receive an update with minor changes, including an updated default theme and branding for terminals that are not configured with custom branding. Our Bolt family of integrated solutions is becoming CardPointe Integrated Payments.
